Features
- Ultrasonic measurement principle, no mechanical wear, long service life.
- Wide range ratio, the measurement grade is better than D grade meter.
- Low starting flow, up to 0.0015m³/h, can realize drip metering.
- The whole machine IP68 protection grade, can work in water for a long time.
- Adopt micro power consumption technology, battery powered, can work continuously for more than 10.
Technical Specifications
| Accuracy Grade | Level 2 |
| Nominal Diameter | DN 15 to DN 25 |
| Range Than | R 250 |
| Max Working Pressure | 1.6 Mpa |
| Temperature Grade | T 30 |
| Sensitivity Level of Upstream Flow Field | U 0 |
| Sensitivity Level of Downstream Flow Field | D 0 |
| Electromagnetic Compatibility Level | E 2 |
| Interface | Optical Interface and NB-Iot |
| The Alarm Reporting | Supports Timely Alarm of Abnormal Data |
| Categories Of Climatic and Mechanical Environmental Conditions | Category C |
| Level Of Protection | Ip 68 |
| Humidity | 100 % Rh |
| Working Power Supply | Battery Powered |
| Temperature | -13 °F to 131 °F (-25 ℃ to 55 ℃) |
| Dimension | 9.84 In X 4.72 In X 3.94 In ( 25 Cm X 12 Cm X 10 Cm) |
| Weight | 1.10 Lb (500 Kg) |
