| Safety specifications |
IEC 61010-1 CAT.IV 600 V, Pollution degree 2 |
| EMC specification |
IEC 61326 EMC specification: electrical equipment for testing, control and inspection |
| Ingress protection |
IEC60529 IP64 (outer box closed state) |
| AC power supply |
220 V ± 10%, 50 Hz to 60 Hz, 20 V A |
| Battery power supply |
16.8 V lithium ion rechargeable battery |
| Battery life time |
10000 V @ 100 m , about 4 hours |
| Test voltage accuracy |
100% to 110% of the nominal value |
| Current test range |
10 mA |
| Current measurement accuracy |
5% + 0.2 nA |
| Short circuit current |
2 mA to 5 mA, adjustable output (10 mA short-circuit current can be customized) |
| Capacitance test range |
20 μF |
| Capacitance test accuracy |
15% + 0.03 μF |
| Discharge rate of capacitor sample |
from 10,000 V to 10 V, 0.5 s/μF |
| Dimensions |
10.24 in × 7.87 in × 6.3 in (260 mm × 200 mm × 160 mm) |
| Weight |
6.6 lb (3000 g) |
