| Detector Type |
Uncooed vanadium oxide VOx Focal plane |
| Detector Resolution |
256 pixel x 192 pixel |
| Thermal Sensitivity |
＜60 mK |
| Frame Rate |
25 Hz |
| Fov |
42° x 32.1° |
| Focusing |
Focus |
| Color Palette |
at least 6 color palettes |
| Visible Light Resolution |
1920 pixel x 1080 pixel |
| Light Supplementary |
Built in LED light |
| Alarm Function |
All temperature measurement points, areas temperature and average temperature can configure separately alarm output |
| Protocol Or Standard |
ONVIF, GB 28181, MODBUS |
| Mobile Format |
MJPEG or H.264 |
| Manual Or Automatic Adjust |
Support |
| Storage Medium |
Built in saver or TF card maximum memory 64 G |
| Picture Storage Mode |
Infrared or visible light separate or simultaneous or Fusion |
| File Format |
JPEG, MP 4 |
| B Or S Configuring Interface |
Available |
| C Or S Configuring Interface |
Available |
| Sdk |
Output externally origin temperature data , Support SDK for user secondary development |
| Power Supply |
DC 12 V |
| Video Interface |
Analog video |
| Network Interface |
including 10 M or 100 M adaptive ethernet port and POE power supply |
| Alarm Interface |
Alarm I or O interface |
| Resolution |
1920 pixel x 1080 pixel |
| Visible Light Fusion |
Dual wave image fusion enhance |
| Accuracy |
±35.6 ℉ (±2 ℃) or reading 2% |
| Point Or Line Or Area |
6 removable points, 1 line, 6 removable areas |
| Preset |
Available |
| Protection Level |
IP 67 |
| Humidity |
≤95% No condensation |
| Range |
-4 ℉ to 248 ℉ (-20 ℃ to 120 ℃) , wide dynamic -4 to 752 ℉ (-20 ℃ to 400 ℃) |
| Working Temperature |
-4 ℉ to 140 ℉ (-20 ℃ to 60 ℃ ) |
| Storage Temperature |
-40 ℉ to 158 ℉ (-40 ℃ to 70 ℃) |
| Dimension |
2.13 in x 0.98 in x 3.11 in (54 mm x 25 mm x 79 mm) |
