Overview
Agro Enviro Tests Color Analyzer Meter is a versatile instrument extensively employed across various industries such as plastics, electronics, painting, ink, textile and garment, printing and dyeing, printing paper, automotive, medical, cosmetics, and the food sector. It is also an indispensable tool for scientific research institutes, educational institutions, schools, and laboratories.
Technical Specifications
| Optical geometry | Integrating sphere |
| Integrating sphere Size | Φ + 1.57 in (40 mm) |
| Light source | Combined full spectrum LED light source |
| Detector | Silicon photodiode array (double row 24 groups) |
| Wavelength range | 400 nm to 700 nm |
| Spectral resolution | 10 nm |
| Measured reflectance range | L: 0 % to 100 %; reflectivity: 0 to 1.0 |
| Measuring aperture | Φ 8 mm (0.315 in) |
| Specular component | SCI |
| Color space | CIE LAB, XYZ, Yxy, Lch |
| Color difference formula | AE ab, AE 00 |
| Observer angle | 10° |
| Illuminant | D 65, A, F2 (CWF) |
| Displayed data | Reflectivity (user-specified wavelength), Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Simulation, Color Offset |
| Displayed accuracy | 0.1 |
