Overview
Agro Enviro Tests Automatic Resistance Meter is an intelligent high-voltage insulation resistance tester with four ranges: 500 V, 1000 V, 2500 V, and 5000 V. The maximum test value can reach 2 TΩ.
Features
- 2 T Ω Insulation resistance at 5 kV
- Adjustable short-circuit current up to 3 mA
- Displays polarization index (PI) and dielectric absorption ratio (DAR)
- Excellent anti-interference performance for accurate testing
- Fast capacitive sample discharge for safety
- Real-time discharge voltage display
- Dual power supply: lithium-ion battery (5-hour life) and AC backup
Technical Specifications
| Safety Specifications | IEC 61010-1 CAT.IV 600V Pollution Degree 2 IEC 61326 EMC Specification IEC 60529 IP 64 (Outer Box Closed State) |
||
| AC Power Supply | 220 V ± 10%, 50/60 Hz, 20 VA | ||
| Battery Power Supply | 8.4 V Lithium-Ion Rechargeable Battery | ||
| Battery Lifetime | 2500 V at 100 M, About 5 Hours | ||
| Test Voltage Accuracy | 100% to 110% of Nominal Value | ||
| Current Test Range | 10 mA | ||
| Current Measurement Accuracy | 5% + 0.2 nA | ||
| Short Circuit Current | 3 mA | ||
| Display Type | Digital Only | ||
| Measuring Range | 0.1m to 400Ω | ||
| Testing Voltage, Range/Accuracy | 500 V, 1000 V, 2500 V, 5000 V | ||
| Accuracy Class | 100% to 110% of Nominal Value | ||
| Operating Temperature | -10 ℉ to 104 ℉ (-10 ℃ to 40 ℃) | ||
| Range Accuracy | 500 V, 1000 V, 2500 V, 5000 V | ||
| Unspecified | <100 k | ||
| Unspecified | >100 G, >200 G, >500 G, > IT | ||
| Dimensions | 10.24 in × 7.87 in × 3.94 in (260 mm × 200 mm × 100 mm) | ||
| Weight | 5.73 lb (2.6 kg) |
